| No. | GENSET Model | OUTPUT POWER 1500RPM 50HZ |
Engine Model | Alternator Model | Dimension | ||||||
| Standby KVA | standby KW | Prime KVA | Prime KW | Isuzu | Leroy Somer | Stamford | Silent Type | Open Type | |||
| 1 | IG17-1P | 23 | 18 | 21 | 17 | 4JB1 | L.S.A43.2 S1 | PI144G | 2050*860*1160 | 1850*850*1160 | |
| 2 | IG20-1P | 28 | 22 | 25 | 20 | 4JB1 | L.S.A43.2 S15 | PI144J | 2050*860*1160 | 1850*850*1160 | |
| 3 | IG22-1P | 31 | 25 | 28 | 22 | 4JB1-T1 | L.S.A43.2 S15 | PI144K | 2050*860*1160 | 1850*850*1160 | |
| 4 | IG26-1P | 36 | 29 | 33 | 26 | 4JB1-T1 | L.S.A43.2 S35 | UCI224D | 2250*860*1160 | 1950*850*1160 | |
| 50HZ, 3 Phases, 400V | |||||||||||
| No. | GENSET Model | OUTPUT POWER 1500RPM 50HZ |
Engine Model | Alternator Model | Dimension | ||||||
| Standby KVA | standby KW | Prime KVA | Prime KW | Isuzu | Leroy Somer | Stamford | Silent Type | Open Type | |||
| 1 | IG18 | 24.75 | 19.8 | 23 | 18 | 4JB1 | L.S.A42.2 M6 | PI144E | 2050*860*1160 | 1850*850*1160 | |
| 2 | IG22 | 30.25 | 24.2 | 28 | 22 | 4JB1 | L.S.A42.2 M7 | PI144F | 2050*860*1160 | 1850*850*1160 | |
| 3 | IG25 | 34.375 | 27.5 | 31 | 25 | 4JB1-T1 | L.S.A42.2 L9 | PI144H | 2050*860*1160 | 1850*850*1160 | |
| 4 | IG29 | 39.875 | 31.9 | 36 | 29 | 4JB1-T1 | L.S.A43.2 S15 | PI144J | 2250*860*1160 | 1950*850*1160 | |
